SWIT BM-U175 17.3-inch 4K/8K 12GSDI Studio Monitor

SWIT - Cameras & Imaging

SWIT BM-U175 17.3-inch 4K/8K 12GSDI Studio Monitor
Thumb 1
Thumb 2
Thumb 3

SWIT BM-U175 17.3-inch 4K/8K 12GSDI Studio Monitor

BM-U175 adopts a 17.3-inch 8-bit+2FRC LCD panel, UHD 3840×2160 resolution, 300nits LED backlight, 800:1 contrast, 91.5% DCI-P3 color gamut. The viewing angle is H178° / V178°.

Features

  • 17.3-inch LCD Panel, 3840×2160 resolution
  • 12GSDI 4-in 4-out, 8K input ready, HDMI®2.0 input
  • 12GSDI via SFP Fiber input (Optional)
  • ST2110 IP via SFP Fiber input (Optional)
  • 3DLUT Auto Self-calibration without PC
  • Audio/Video 0 latency for lip-sync
  • HLG/PQ/S-log3 HDR EOTF
  • Payload ID auto setting
  • Built-in Multi camera Delog LUTs
  • User 3DLUTs upload via USB
  • Waveform / Vector / Histogram
  • Focus assist / False color / Zebra
  • 16-ch audio meters / Lissajous
  • IP webserver remote control
  • TSL UMD and text TALLY display
  • USB firmware upgrade
  • 19-inch rack mountable, 7U height

Downloads

Datasheet
