SWIT BM-U245HDR 23.8-inch 4K/8K 12GSDI HDR Studio Monitor

SWIT - Cameras & Imaging

SWIT BM-U245HDR 23.8-inch 4K/8K 12GSDI HDR Studio Monitor
Thumb 1
Thumb 2
Thumb 3

SWIT BM-U245HDR 23.8-inch 4K/8K 12GSDI HDR Studio Monitor

BM-U245HDR adopts a 23.8-inch 10-bit LCD panel, UHD 3840×2160 resolution, 1000nits LED backlight, 1000:1 contrast, 91.9% DCI-P3 and 89% Rec2020 color gamut. The viewing angle is H178° / V178°.

Features

  • 23.8-inch LCD panel, 3840×2160 resolution
  • 1000nits high bright LED backlight
  • HLG/PQ/S-log3 HDR, payload ID auto setting
  • 12G-SDI 4-in 4-out, 8K input ready, HDMI® 2.0 input
  • 12G-SDI via SFP fiber input (optional)
  • ST2110 IP via SFP fiber input (optional)
  • SFP fiber 12G input converted to 12G-SDI out
  • 3D LUT auto self-calibration without PC
  • Audio/video zero latency for lip-sync
  • Built-in multi camera Delog LUTs
  • User 3D LUTs upload via USB
  • Waveform / vector / histogram
  • Focus assist / false color / zebra
  • 16-ch audio meters / Lissajous
  • IP webserver remote control
  • TSL UMD and text TALLY display
  • USB firmware upgrade

Downloads

Datasheet
